BTEng — Behavior Tree Engine

BTEng — Behavior Tree Engine for Python

BTEng is a modular, production-grade Behavior Tree execution engine for Python. It is designed for robotics, automation, simulation, and any tick-driven control system that needs robust, reactive decision-making.

The library provides a compact core runtime, a rich node library, a thread-safe blackboard, XML tree loading, plugin-based custom nodes, execution tracing, structured logging, runtime introspection, and optional ZMQ event streaming — without imposing a large framework on your application.

Features
Installation
Quick Start
Core Concepts
Custom Nodes
XML Trees
Introspection & Logging
Execution Tracing & Replay
ZMQ Event Streaming
Unit Testing
CLI
Documentation
License

Features

Category	Capabilities
Execution	Tick-based engine, event-loop executor, pause/resume, max-tick budget
Control nodes	`Sequence`, `Fallback`/`Selector`, `Parallel`, `ReactiveSequence`, `ReactiveFallback`
Decorators	`Inverter`, `Retry`, `Timeout`, `RateController`, `ForceSuccess`, `ForceFailure`
Leaf nodes	`ActionNode`, `ConditionNode`, `StatefulActionNode`, `AsyncActionNode`
Blackboard	Scoped, observable, provenance history, schema validation, change subscriptions
Builder API	Fluent `TreeBuilder` for programmatic tree construction
XML loader	Full XML parser with port-default resolution and subtree support
Factory	`@register_node` decorator, `NodeManifest`, dynamic plugin loading
Introspection	`Inspector` — per-node stats, active-path tracking, explain log
Logging	`Logger` — console and JSON-lines sinks, auto-wired to Inspector
Tracing	`ExecutionTracer` — per-tick frame recording, JSON export, replay
Concurrency	`ThreadPool` (auto-injected), `CancellationToken` for async actions
Testing	`MockActionNode`, `MockConditionNode`, `BehaviorTreeTest`
Streaming	`ZmqPublisher` — streams tick events via ZMQ PUB (optional dep)
CLI	`bteng run` for command-line tree execution

Installation

From PyPI

pip install bteng

Optional extras

pip install "bteng[zmq]"   # ZMQ publisher — stream tick events to dashboards
pip install "bteng[dev]"   # Development tools: pytest, build, twine

Requirements: Python 3.9 or newer.

Quick Start

For new code, start with TreeBuilder + TreeExecutor.

from bteng import (
    Blackboard,
    NodeStatus,
    TreeBuilder,
    TreeExecutor,
)

bb = Blackboard.create("demo")
bb.set("battery_level", 87)

tree = (
    TreeBuilder(blackboard=bb)
    .tree_id("Mission")
    .sequence("root")
        .condition("BatteryOK", lambda: bb.get("battery_level", 0) > 20)
        .action("Navigate",     lambda: NodeStatus.SUCCESS)
    .end()
    .build()
)

executor = TreeExecutor()
executor.set_tree(tree)
status = executor.tick_until_result(max_ticks=100)
print(status)  # NodeStatus.SUCCESS

BehaviorTreeEngine is still available for legacy code, but TreeExecutor is the recommended runtime for new projects.

Core Concepts

Status model

Every node returns a NodeStatus each tick:

Status	Meaning
`SUCCESS`	Node completed successfully
`FAILURE`	Node failed
`RUNNING`	Node is active and must be ticked again
`IDLE`	Node is inactive or has been halted

Control nodes

Node	Behavior
`Sequence`	Ticks children left-to-right; stops at first `FAILURE` or `RUNNING`
`Fallback` / `Selector`	Ticks children left-to-right; stops at first `SUCCESS` or `RUNNING`
`Parallel`	Ticks all children simultaneously with configurable success/failure thresholds
`ReactiveSequence`	Restarts from child[0] every tick; earlier conditions interrupt later actions
`ReactiveFallback`	Restarts from child[0] every tick; higher-priority child can preempt

Decorators

Decorator	Purpose
`Inverter`	Swaps `SUCCESS` ↔ `FAILURE`; passes `RUNNING` unchanged
`Retry(max_attempts)`	Retries child on `FAILURE` up to N times
`Timeout(duration)`	Returns `FAILURE` if child exceeds duration (seconds)
`RateController(hz)`	Rate-limits child ticking; returns cached status between ticks
`ForceSuccess`	Always returns `SUCCESS` unless child is `RUNNING`
`ForceFailure`	Always returns `FAILURE` unless child is `RUNNING`

Blackboard

A thread-safe, scoped key-value store shared across the tree:

from bteng import Blackboard

bb = Blackboard.create("robot")
bb.set("pose", (1.0, 2.0, 0.0))
bb.set("stopped", None)       # None is a valid stored value

bb.get("pose")                # (1.0, 2.0, 0.0)
bb.get("stopped")             # None  (the stored None, not a missing-key default)
bb.has("stopped")             # True

# Change subscriptions
sub = bb.subscribe(lambda key, val: print(f"{key} changed to {val}"))
bb.set("pose", (2.0, 3.0, 0.0))  # fires callback
bb.unsubscribe(sub)

# Scoped child blackboard for subtree port isolation
child = bb.create_child_scope("subtree", remapping={"local_goal": "goal"})
child.set("local_goal", "dock")   # transparently writes bb["goal"]
child.get("local_goal")           # transparently reads bb["goal"]

Custom Nodes

Define new node types by subclassing and declaring ports:

from bteng import ActionNode, InputPort, OutputPort, NodeStatus, register_node


@register_node()
class DetectObject(ActionNode):
    @classmethod
    def provided_ports(cls):
        return [
            InputPort("camera", default="rgb"),
            OutputPort("object_pose"),
        ]

    def tick(self) -> NodeStatus:
        camera = self.get_input("camera")   # resolves XML attribute or default
        pose   = run_detector(camera)
        if pose is None:
            self.set_failure_reason("detector returned no result")
            return NodeStatus.FAILURE
        self.set_output("object_pose", pose)
        return NodeStatus.SUCCESS

Access the full node configuration via self.config (NodeConfig with blackboard, port mappings, and static params). self.blackboard is a convenience shortcut.

For long-running work use StatefulActionNode (three-phase lifecycle: on_start / on_running / on_halted) or AsyncActionNode (runs execute_async(token) in a background thread; the executor automatically injects a shared ThreadPool).

XML Trees

Load and execute trees defined in XML — useful for decoupling behavior from code:

<?xml version="1.0" encoding="UTF-8"?>
<BTEng format_version="1.0" main_tree_to_execute="main">
  <Tree ID="main">
    <ReactiveFallback name="root">
      <ReactiveSequence name="navigate_if_safe">
        <Condition ID="PathClear"/>
        <Timeout duration="10.0">
          <Action ID="NavigateTo" goal="{target_goal}"/>
        </Timeout>
      </ReactiveSequence>
      <Action ID="StopRobot"/>
    </ReactiveFallback>
  </Tree>

  <TreeNodesModel>
    <Condition ID="PathClear"/>
    <Action ID="NavigateTo">
      <input_port name="goal"/>
    </Action>
    <Action ID="StopRobot"/>
  </TreeNodesModel>
</BTEng>

Port syntax:

goal="{target_goal}" — blackboard reference; reads/writes key target_goal
mode="inspection" — static literal parameter
InputPort(default=...) is applied when the XML attribute is absent

from bteng import XMLTreeParser, Blackboard

bb   = Blackboard.create("demo")
bb.set("target_goal", "dock_station")

parser = XMLTreeParser()
root   = parser.parse_file("mission.xml", blackboard=bb)

See docs/reference/xml.md for the full specification.

Introspection & Logging

Attach an Inspector and Logger to any TreeExecutor — no changes to node code required:

from bteng import Inspector, Logger, LogLevel, TreeExecutor

inspector = Inspector.create()
logger    = Logger.create()
logger.add_console_sink(colored=True)
logger.add_json_file_sink("/tmp/bt_run.jsonl")

executor = TreeExecutor()
executor.set_tree(tree)
executor.set_inspector(inspector)
executor.set_logger(logger)       # auto-wired; no extra setup needed
executor.tick_until_result()

# Per-node statistics
for uid, stats in inspector.all_stats().items():
    print(f"{uid:40s}  ticks={stats.tick_count:4d}  "
          f"total={stats.total_duration*1000:.1f}ms")

Execution Tracing & Replay

Record every tick for offline analysis, regression testing, or replay:

from bteng import ExecutionTracer, TreeExecutor

tracer   = ExecutionTracer()
executor = TreeExecutor()
executor.set_tree(tree)
executor.set_tracer(tracer)
executor.tick_until_result()

# Export full trace
with open("trace.json", "w") as f:
    f.write(tracer.export_json())

# Compact replay format (smaller file)
with open("replay.json", "w") as f:
    f.write(tracer.export_replay())

# Load and inspect a previously recorded run
tracer2 = ExecutionTracer()
tracer2.load_replay(open("replay.json").read())
frame = tracer2.replay_frame(0)
print(frame.tick_index, frame.blackboard_snapshot)

ZMQ Event Streaming

Stream tick events to an external dashboard or visualiser with zero coupling between the engine and the consumer:

pip install "bteng[zmq]"

from bteng.introspection import ZmqPublisher

pub = ZmqPublisher(port=1667)   # default port — compatible with BehaviorTree.CPP convention
pub.attach(inspector)
pub.start()

# ... run tree as normal ...

pub.stop()

Each published message is a JSON object on ZMQ topic bteng:

{
  "ts":     1234.567,
  "uid":    "a1b2c3d4",
  "name":   "NavigateTo",
  "type":   "action",
  "status": "SUCCESS",
  "dur_ms": 12.3,
  "reason": ""
}

Unit Testing

BehaviorTreeTest and MockActionNode / MockConditionNode provide a purpose-built test harness:

from bteng import (
    MockActionNode, MockConditionNode, BehaviorTreeTest,
    NodeStatus, SequenceNode, Tree, TreeMetadata,
)

condition = MockConditionNode("IsReady")
condition.set_result(True)

action = MockActionNode("Navigate")
action.set_ticks_to_complete(3)    # returns RUNNING for 2 ticks, then SUCCESS

root = SequenceNode("root", children=[condition, action])
tree = Tree(TreeMetadata(id="test"), root)

result = (
    BehaviorTreeTest(tree)
    .expect_final_status(NodeStatus.SUCCESS)
    .set_max_ticks(10)
    .run()
)
assert result, result.error_message

CLI

Execute and visualize trees from the command line:

bteng run mission.xml --plugin my_robot_nodes.py --tree main --hz 10 --log run.json -v

Documentation

Document	Contents
5-minute Quick Start	Recommended first tree with `TreeBuilder + TreeExecutor`
Which API should I use?	Decision table for Python, XML, legacy, and advanced APIs
Beginner Guide	Behavior-tree basics, blackboard, TreeBuilder, and first tests
Advanced Guide	Ports, reactive internals, plugins, introspection, ZMQ, runtime modification
Architecture	Component relationships and data-flow diagram
XML specification	Full XML format reference with port syntax
Node system	Node lifecycle, port model, custom node authoring

License

BTEng is distributed under a proprietary license. See LICENSE for terms.
